Mancooler
Mancooler Manufacturer
TECHNICAL SPECIFICATIONS OF INDUSTRIAL TYPE HEAVY DUTY MANCOOLER
Performance figues of fans tested as per ISS 6272 with tolerance mentioned therein
| Sweep | Speed | Motor | Total air delivery at | Minimum peak air | ||
| MM(Inch) | (R.P.M) | (H.P) | 10 times blade sweep | velocity at a distance of | ||
| CFM | M³/Hr | 10 times blade sweep m/min | 15 times blade sweep m/min | |||
| *300 (12”) | 2850 | 0.5 | 5250 | 9000 | 250 | 200 |
| *480 (19”) | 1440 | 0.5 | 7000 | 12000 | 200 | 120 |
| 480 (19”) | 2900 | 3 | 12000 | 22000 | 250 | 200 |
| *600 (24”) | 1440 | 1 | 16500 | 28000 | 250 | 150 |
| 750(30”) | 1440 | 2 | 22000 | 37000 | 250 | 150 |
| 900(36”) | 960 | 2 | 33000 | 56000 | 250 | 150 |
| 900(36”) | 1440 | 3 | 38000 | 65000 | 275 | 175 |
| 1000(40”) | 1440 | 4 | 42000 | 72000 | 250 | 150 |
